Alerta Care Universal Delivery Robot
Robot Architecture and Desciption
• Cloud Solution | • Standalone Solution
Cloud Solution Architecture Diagram
1. To achieve the linkage between robots and the nurse-patient intercomsystem,Intelligent
ward management system needs to be connected to the network and have open ports.
2. The robot cloud platform has the following functions:
- View Robot Operation Data Report;
- Robot remote one-click call function;
- Remote status monitoring of robots;
- Robot Task History;
- Custom Scheduling for Robot Tasks;
- Remote viewing of robot logs;
3. According to the requirements, the robot will be equipped with a router that supports thefrequency bands of the corresponding country, and the user needs to provide their ownIoTSIM card to insert into the robot.
4. A mobile app is provided, which allows users to remotely call the robot with one click, viewhistorical task records, and other functions. Users need to have an Android phone or tablet
and ensure that the device is connected to the internet.
Standalone solutionarchitecturediagram
1. The standalone version does not havethefunctions of the robot cloudplatform, butitcan perform delivery tasks normally；
2. The standalone version uses elevatorcontrol module and door control module；
3. Advantages of standalonerobots：
- No need to connect to thecloudplatform,saving costs
- No complex network environmentrequired, easy to deploy
Cloud Solution VS Standalone Solution
